2.10 ConsoleEDS – Command Line control
ConsoleEDS is a powerful software utility which allows any Equinox ISP Programmer to be controlled
from a custom Remote Application running under Windows.
The main features of ConsoleEDS are:
?
?
?
?
?
?
?
?
?
?
?
Allows an Equinox ISP Programmer to be remote controlled via simple Command Line
commands.
Suitable for interfacing to any application which executes under Windows
Simple Command Line interface makes even complex programming operations simple to
implement
Supports writing of a block of data from a file to the FLASH or EEPROM of a Target Chip
Supports reading of a block of data from the FLASH or EEPROM of the Target Chip to a file
on the PC hard disk
Supports uploading of pre-compiled standalone ‘Programming Projects’ to a target
programmer without requiring EQTools or the Project Upload Wizard.
Supports running of a specified ‘Standalone Programming Project’ which has already been
uploaded into the programmer ‘FLASH Memory Store’
Supports programming of the ‘Configuration Fuses’ of the Target Chip
Supports programming of the ‘Security Fuses’ of the Target Chip
Supports automatic generation of and programming of unique information such as serial
numbers and calibration data
Supports reading / writing of Atmel AVR on-chip Oscillator Calibration Byte
Please note:
Many of the above features are only accessible when using ‘ConsoleEDS PRO’ .
Typical ConsoleEDS example:
ConsoleEDS BaseProject.prj /AUTOPROGRAM=MainFirmware
/EEPROMWRITE=CalData.hex,0,50
For further information about ConsoleEDS, please refer to Application Note 111.
ISPnano Series Programmer - User Manual – V1.11 – 12 May 2011
th
37
